RS1102 Brushless Motor - High Performance for Miniature Drones

The RS1102 is a high-performance brushless motor designed for mini drones, offering two KV options of 10000KV and 13500KV for various flying needs. With a lightweight design and a stator diameter of 11mm, it's perfect for racing and freestyle drones, such as the Mobula7 O4 when equipped with the 10000KV motor.

Product Features

1. KV Options – Choose between 10000KV (for Mobula7 O4) and 13500KV for different flight styles and power demands.

2. Lightweight Design – Weighing only 2.8g, it’s ideal for lightweight drone builds.

3. High Efficiency – With a 9N12P configuration, this motor provides smooth and stable performance for small drones.

4. Durable Shaft – Features a Φ1.5mm shaft diameter, making it suitable for high-speed flights with durability in mind.

5. Recommended Battery – Works best with a 2S battery for optimal power and control.

Specifications

Motor Specifications

• Model: RS1102

• KV Options: 10000KV or 13500KV

• Configuration: 9N12P

• Stator Diameter: 11mm

• Stator Length: 2mm

• Shaft Diameter: Φ1.5mm

• Motor Dimensions: Φ13.5mm x 14mm

• Weight: 2.8g

• Recommended Battery: 2S

Ideal for lightweight drone applications, the RS1102 Brushless Motor provides high efficiency, excellent power output, and a low weight, making it a top choice for miniature drones like the Mobula7 O4.
